Famous CAD Construction Atlas

From the aspect of functional space, the book is divided into five parts: hotel space, business & office space, restaurant space, leisure & entertainment space and exhibition space. In the hotel space, this book selects hotels designed by well-known international design groups. You can comprehend the design classics of big groups through drawings of the hotel's public areas, lobby, banquet hall, rooms and so on. In the exhibition space, popular 2010 Shanghai World Expo pavilions are the main selection. The pomp of the 2010 Shanghai World Expo is recreated by displaying pavilion’s external shape, entrance and internal structure. In other spaces, you can learn about the building process of business environment by displaying functions of shopping malls, office decoration, stores, restaurants, KTV, leisure clubs and so on.
From the aspect of CAD drawings design, all selected drawings are domestic and international first-class drawings, and even built drawings. In addition, there are also corresponding real and effect maps. These drawings are very detailed and from big companies, including HBA, Gold Mantis, the United States Wilson, Tdi Associates (Shanghai) Pte, Ltd, and famous designers, including Gao Wenan, Xie Yingkai, Zhang Xing and so on. You can not only refer to their design but also quote something inside the drawings. For example, you can adjust the size of hardware structural elements to standard size for the next need; at the same time, it’s worth for you to collect some detailed and standard methods such as identification methods of icons, illustration, material and process. All these can enrich your own map storage or perfect your company’s storage.
